| Image | SKU# | Étiquette schéma | Description | Demander un prix |
|---|---|---|---|---|
|
NA607004000 | 300 to 335 | C4 kit (wet pick-up) | Demander un prix |
|
|
NA607005000 | 300 to 335 | C5 kit (wet pick-up) | Demander un prix |
|
|
NA607006000 | 300 to 335 | C6 kit (wet pick-up) | Demander un prix |
|
NA21965V000 | 300 | M6 x 40mm long hex bolt | Demander un prix |
|
NA219007000 | 301 | M6 form b washer | Demander un prix |
|
NA215006000 | 302 | 51mm diameter black & grey wheel | Demander un prix |
|
NA204023000 | 303 | 24mm long wheel insert | Demander un prix |
|
NA219008000 | 304 | M6 form g washer | Demander un prix |
|
NA214114000 | 305 | Body moulding c/w inserts | Demander un prix |
|
NA219078000 | 306 | M8 nylon insert nut | Demander un prix |
|
NA217213000 | 307 | Front & rear rubber blades (kits: c2, c3) | Demander un prix |
|
NA217218000 | Rear brush strip (kits: c4, c5, c6) | Demander un prix | |
|
NA217217000 | Front castellated brush strip (kits: c4, c5, c6) | Demander un prix | |
|
NA208008000 | 309 | Shouldered bush | Demander un prix |
|
NA219312000 | 310 | Compression spring | Demander un prix |
|
NA414032000 | 311 | Wheel bracket | Demander un prix |
|
NA219010000 | 312 | M8 form a washer | Demander un prix |
|
NA429008000 | 313 | Link rod | Demander un prix |
|
NA219403000 | 314 | 8mm starlock washer & cap | Demander un prix |
|
NA429007000 | 315 | Link rod & welded pin | Demander un prix |
|
NA219101000 | 316 | No8 X 1/2 INCH LONG POZI PAN PLASTIITE SCREW | Demander un prix |
|
NA219005000 | 317 | M5 form g washer | Demander un prix |
|
NA219530000 | 318 | Compression spring | Demander un prix |
|
NA403234000 | 319 | Angle bracket | Demander un prix |
|
NA219544000 | 320 | M6 shakeproof washer | Demander un prix |
|
NA219455000 | 321 | m6 x 20mm long hex head screw | Demander un prix |
|
NA314004000 | 322 | Adjusting screw | Demander un prix |
|
NA219417000 | 323 | Insulator bush | Demander un prix |
|
NA216134000 | 324 | Floor tool handle | Demander un prix |
|
NA219079000 | 325 | M8 plain nut | Demander un prix |
|
NA021937000 | 326 | No8 X 5/8 INCH LONG PLASTITE STAINLESS STEEL SCREW | Demander un prix |
|
NA219272000 | 327 | "E" type circlip/6mm | Demander un prix |
|
NA219088000 | 328 | M6 nylon insert nut | Demander un prix |
|
NA206283000 | 329 | Securing arm | Demander un prix |
|
NA215019000 | 330 | Moulded bracket | Demander un prix |
|
NA219529000 | 331 | Stainless steel hose clamp (45mm - 60mm) | Demander un prix |
|
NA603005000 | 332 | 520mm Hiloflex Black Hose Assembly (C2 Kit) | Demander un prix |
|
NA603003000 | 730mm Hiloflex Black Hose Assembly (C3 Kit) | Demander un prix | |
|
NA213997000 | 245mm black hose assembly (c4 kit) | Demander un prix | |
|
NA213998000 | 450mm black hose assembly (c5 kit) | Demander un prix | |
|
NA213999000 | 860mm black hose assembly (c6 kit) | Demander un prix | |
|
NA219018000 | 333 | M8 shakeproof washer | Demander un prix |
|
NA217212000 | 334 | Brush holder extrusion (kits: c4, c5, c6) | Demander un prix |
|
NA21982V000 | 335 | M8 x 40mm long head bolt | Demander un prix |
