| Image | SKU# | Étiquette schéma | Description | Demander un prix |
|---|---|---|---|---|
|
NA237594000 | 1 | Rsv switch module housing (1/2) | Demander un prix |
|
NA237595000 | 2 | Rsv switch module housing (2/2) | Demander un prix |
|
NA237585000 | 3 | Rsb inner motor sleeve | Demander un prix |
|
NA237588000 | 4 | Rsb battery release catch | Demander un prix |
|
NA237586000 | 5 | Wire management insert | Demander un prix |
|
NA237589000 | 6 | Rsb cable housing front | Demander un prix |
|
NA237597000 | 7 | Battery release toggle - hinge pin | Demander un prix |
|
NA237582000 | 8 | Pcb bracket | Demander un prix |
|
NA237590000 | 9 | Rsb cable housing back | Demander un prix |
|
NA237584000 | 10 | Rsb top motor housing | Demander un prix |
|
NA237583000 | 11 | Rsb battery housing | Demander un prix |
|
NA237587000 | 12 | Rsb lower fascia | Demander un prix |
|
NA237457000 | 12 | Rsb lower fascia (black) (mid blue & royal blue machines) | Demander un prix |
|
NA321923000 | 13 | Rsb switch cable loom | Demander un prix |
|
NA230231000 | 13 | Rsb usa / csa cable loom assembly (usa) | Demander un prix |
|
NA208625000 | 14 | Led display | Demander un prix |
|
NA230097000 | 15 | Axial ferrite bead | Demander un prix |
|
NA208559000 | 16 | Power control pcb. Synchronous buck converter | Demander un prix |
|
NA230223000 | 17 | Battery vac connecting pcb | Demander un prix |
|
NA227199000 | 19 | Diffuser moulding (bec) | Demander un prix |
|
NA206509000 | 20 | Back support moulding (long) | Demander un prix |
|
NA604914000 | 21 | Filter assembly pour aspirateur RSV et RBV 130 | Demander un prix |
|
NA227186000 | 22 | Toggle moulding | Demander un prix |
|
NA206326000 | 23 | Toggle pin | Demander un prix |
|
NA227183000 | 24 | Lid moulding | Demander un prix |
|
NA328130000 | 25 | Rsv 130 body moulding (mid blue) | Demander un prix |
|
NA328149000 | 25 | Rsv 130 body moulding (red) | Demander un prix |
|
NA328964000 | 25 | Rsv 130 body moulding (royal blue printed white nacecare) | Demander un prix |
|
NA392305000 | 26 | Remote cable clamp | Demander un prix |
|
NA216465000 | 27 | 11mm coil spring | Demander un prix |
|
NA219667000 | 28 | No6 X 1/2" LONG PLASTITE SCREW | Demander un prix |
|
NA219602000 | 29 | No6 X 1 INCH LONG POZI PAN PLASTITE SCREW | Demander un prix |
|
NA219601000 | 30 | No8 X 3/8 INCH LONG POZI PAN PLASTITE SCREW | Demander un prix |
|
NA219101000 | 32 | No8 X 1/2 INCH LONG POZI PAN PLASTIITE SCREW | Demander un prix |
|
NA219105000 | 33 | No8 X 5/8 INCH LONG POZI PAN PLASTITE SCREW | Demander un prix |
|
NA219720000 | 34 | M5 x 30mm long stainless steel pozi pan screw | Demander un prix |
|
NA219644000 | 35 | M5 form g stainless steel washer | Demander un prix |
|
NA219076000 | 36 | M5 nylon insert nut | Demander un prix |
|
NA206599000 | 37 | Spring (ref:c5514370) | Demander un prix |
|
NA291049000 | 38 | No8 x 2.95 tx-pn-plast screw | Demander un prix |
|
NA209085000 | 39 | Rsb burst bag filter | Demander un prix |
|
NA209084000 | 40 | Rsb diffuser grille foam | Demander un prix |
|
NA209083000 | 41 | Rsb motor side accoustic barrier | Demander un prix |
|
NA209082000 | 42 | Rsb motor top acoustic barrier | Demander un prix |
|
NA206353000 | 43 | Harness pin | Demander un prix |
|
NA216655000 | 44 | Battery release spring | Demander un prix |
|
NA206462000 | 45 | Rsv harness assembly | Demander un prix |
|
NA220243000 | 46 | Switch.spdt.rkr.hv | Demander un prix |
|
NA237591000 | 47 | Battery release base moulding | Demander un prix |
|
NA237592000 | 48 | Battery release top moulding | Demander un prix |
|
NA237593000 | 49 | Locking cap | Demander un prix |
|
NA902326000 | 50 | 36V DC 1 STAGE MOTOR | Demander un prix |
|
NA237617000 | 51 | Motor top mount | Demander un prix |
|
NA237616000 | 52 | Motor gasket | Demander un prix |
