| Image |
SKU# |
Étiquette schéma |
Description |
Demander un prix |
|
HW080174681
|
1 |
Bag housing cover grey |
Demander un prix
|
|
HW100093001
|
3 |
Grill filter holder red |
Demander un prix
|
|
HW084580081
|
4 |
Safety support kit |
Demander un prix
|
|
HW015230316
|
5 |
Internal filter |
Demander un prix
|
|
HW084370081
|
6 |
Bag entrance w/safety support |
Demander un prix
|
|
HW084520081
|
7 |
Handle button assembly 2 pos. |
Demander un prix
|
|
HW031460310
|
8 |
Round dusting brush |
Demander un prix
|
|
HW001830105
|
9 |
Round dusting brush support |
Demander un prix
|
|
HW083194681
|
10 |
Bag housing complete |
Demander un prix
|
|
HW080790081
|
11 |
Valve kit |
Demander un prix
|
|
HW011050016
|
12 |
Valve filter |
Demander un prix
|
|
HW010260307
|
13 |
O-ring |
Demander un prix
|
|
HW181460381
|
14 |
Extension hose with handle grip |
Demander un prix
|
|
HW002730104
|
15 |
Wand clip |
Demander un prix
|
|
HW004601701
|
16 |
Switch button |
Demander un prix
|
|
HW081443881
|
17 |
Blue handle |
Demander un prix
|
|
HW007791201
|
18 |
Adapter |
Demander un prix
|
|
HW084590081
|
19 |
Cromate tube |
Demander un prix
|
|
HW001680304
|
20 |
Cord clip v.230/240 |
Demander un prix
|
|
HW181354680
|
22 |
Elec.system ass.120/60 |
Demander un prix
|
|
HW010830307
|
24 |
Strain relief v.100/120 d.8 |
Demander un prix
|
|
HW000460307
|
24 |
Strain relief d.6 v.100/230/240 |
Demander un prix
|
|
HW000070305
|
25 |
Cord clamp |
Demander un prix
|
|
HW024590000
|
26 |
Vacuum sensor |
Demander un prix
|
|
HW024660000
|
28 |
Main switch |
Demander un prix
|
|
HW004610835
|
29 |
Red lens |
Demander un prix
|
|
HW100023801
|
31 |
Hook central handle blue |
Demander un prix
|
|
HW181504681
|
32 |
Cover handle |
Demander un prix
|
|
HW009170101
|
34 |
Contact cover |
Demander un prix
|
|
HW100010301
|
35 |
Frame handle |
Demander un prix
|
|
HW010200016
|
36 |
Foam filter |
Demander un prix
|
|
HW000200308
|
37 |
Gasket |
Demander un prix
|
|
HW020040400
|
38 |
Terminal block 2 poles |
Demander un prix
|
|
HW020340400
|
38 |
Terminal block 3 poles |
Demander un prix
|
|
HW011790016
|
39 |
Foam motor filter |
Demander un prix
|
|
HW007940308
|
40 |
Gasket new |
Demander un prix
|
|
HW082723881
|
41 |
Bag door latch + spring blue |
Demander un prix
|
|
HW083770081
|
42 |
Exhaust microf.5 pcs (dp5/hf6/ |
Demander un prix
|
|
HW003360100
|
43 |
Exhaust grill |
Demander un prix
|
|
HW181514681
|
44 |
Front grill grey |
Demander un prix
|
|
HW003980133
|
46 |
Blocking joint pin support |
Demander un prix
|
|
HW010840009
|
47 |
Joint pin |
Demander un prix
|
|
HW001503805
|
48 |
Control pin slide blue |
Demander un prix
|
|
HW003964644
|
49 |
Vacuum motor housing |
Demander un prix
|
|
HW001760331
|
50 |
Lower curve |
Demander un prix
|
|
HW084610380
|
51 |
Curve support v.100-120-240 2 wires |
Demander un prix
|
|
HW084610080
|
51 |
Curve support v.120/60 3 wires for |
Demander un prix
|
|
HW001750331
|
52 |
Upper curve |
Demander un prix
|
|
HW010270307
|
53 |
O ring |
Demander un prix
|
|
HW081204681
|
54 |
Inner vacuum motor housing |
Demander un prix
|
|
HW003970133
|
55 |
Hose inlet rx hepa |
Demander un prix
|
|
HW180710080
|
56 |
Cord clamp w/out elect.2 wires |
Demander un prix
|
|
HW180820080
|
56 |
Cord clamp w/out elect.3 wires |
Demander un prix
|
|
HW051410080
|
57 |
Vacuum motor r26apss (he) v.100/55 |
Demander un prix
|
|
HW051350080
|
57 |
Vacuum motor r26apss (he) v.120/60 |
Demander un prix
|
|
HW051340081
|
57 |
Vacuum motor r26apss (he) v.240/50 |
Demander un prix
|
|
HW010220016
|
58 |
Foam filter |
Demander un prix
|
|
HW030060310
|
59 |
Crevice tool |
Demander un prix
|
|
HW032350300
|
60 |
Telescopic wand for rx |
Demander un prix
|
|
HW009180003
|
61 |
Contact cover 4 pos. New |
Demander un prix
|
|
HW009190003
|
62 |
Contact housing 4 pos. New |
Demander un prix
|
|
HW009160101
|
63 |
Contact housing |
Demander un prix
|
|
HW181523881
|
64 |
Botton cover kit blue |
Demander un prix
|
|
HW088020009
|
65 |
Screw 3,5x13 (wrapping of 20 pcs) |
Demander un prix
|
|
HW180680009
|
66 |
Wrapping of 20 pcs screw 3,5x57 |
Demander un prix
|
|
HW087250009
|
67 |
Screw 3,5x22 (wrapping of 20 pcs) |
Demander un prix
|
|
HW087050009
|
68 |
Screw 3,5x16 (wrapping of 20 pcs) |
Demander un prix
|
|
HW085550009
|
69 |
Wrapping of 20 pcs screw 3,5x25 |
Demander un prix
|
|
HW086440009
|
70 |
Wrapping of 20 pcs screw 3,5x19 |
Demander un prix
|
|
HW085590009
|
71 |
Screw 3,9x13 (wrapping of 20 pcs) |
Demander un prix
|
|
HW087260009
|
72 |
Screw 3,9x22 (wrapping of 20 pcs) |
Demander un prix
|
|
HW085610009
|
73 |
Screw 2,9x16 (wrapping of 20 pcs) |
Demander un prix
|
|
HW085560009
|
74 |
Wrapping of 20 pcs screw 3,9x16 |
Demander un prix
|
|
HW012980009
|
75 |
Handle spring |
Demander un prix
|
|
HW009893801
|
76 |
Button blue |
Demander un prix
|
