| Image | SKU# | Label on drawing | Description | Ask for a price |
|---|---|---|---|---|
|
NA227115000 | 1 | Toggle | Ask for a price |
|
NA202069000 | 2 | Bottom motor gasket | Ask for a price |
|
NA305424000 | 3 | 220V 2 STAGE BP MOTOR | Ask for a price |
|
NA205815000 | 3 | 115v motor | Ask for a price |
|
NA202085000 | 4 | Top seal | Ask for a price |
|
NA202080000 | 5 | Top gasket | Ask for a price |
|
NA219380000 | 6 | Barbed tube fitting gve machines | Ask for a price |
|
NA219337000 | 7 | Locknut | Ask for a price |
|
NA219299000 | 8 | Blocking nut | Ask for a price |
|
NA227995000 | 9 | 235mm long solution tube | Ask for a price |
|
NA227998000 | 10 | 260mm long solution tube gve machines | Ask for a price |
|
NA219281000 | 11 | Tube spring gve machines | Ask for a price |
|
NA502040000 | 12 | Gauze filter assembly gve machines | Ask for a price |
|
NA216147000 | 13 | Pump small bore 220/240v/50hz | Ask for a price |
|
NA216143000 | 13 | Pump small bore 220/240v 60hz | Ask for a price |
|
NA216144000 | 13 | Pump small bore 100v 60hz | Ask for a price |
|
NA216145000 | 13 | Pump small bore 100v 50hz | Ask for a price |
|
NA216148000 | 13 | Pump small bore 210v 50hz | Ask for a price |
|
NA206208000 | 14 | Sealing washer | Ask for a price |
|
NA303022000 | 15 | Pump fixing bracket | Ask for a price |
|
NA216296000 | 16 | Quick release bulkhead fitting | Ask for a price |
|
NA227814000 | 17 | 215mm long solution tube | Ask for a price |
|
NA219107000 | 18 | No6 x 5/8 inch long pozi pan plastite screw | Ask for a price |
|
NA220472000 | 19 | Terminal block mould + inserts | Ask for a price |
|
NA220289000 | 20 | Suppressor | Ask for a price |
|
NA220843000 | 21 | Blue rocker switch | Ask for a price |
|
NA220670000 | 22 | Switch cover | Ask for a price |
|
NA227008000 | 23 | Black cable clamp | Ask for a price |
|
NA219101000 | 24 | No8 X 1/2 INCH LONG POZI PAN PLASTIITE SCREW | Ask for a price |
|
NA220923000 | 25 | Stress relief | Ask for a price |
|
NA219090000 | 26 | M4 x 8mm long pozi pan sems screw | Ask for a price |
|
NA320296000 | 28 | 340mm long white link wire | Ask for a price |
|
NA320550000 | 29 | 100mm long brown link wire | Ask for a price |
|
NA320551000 | 30 | 100mm long blue link wire | Ask for a price |
|
NA320555000 | 31 | Diode assembly | Ask for a price |
|
NA227019000 | 32 | Cable hook | Ask for a price |
|
NA219369000 | 33 | No8 X 1 INCH LONG POZI PAN STAINLESS STEEL PLASTITE SCREW | Ask for a price |
|
NA219041000 | 34 | No8 X 3/4 INCH LONG POZI PAN SCREW | Ask for a price |
|
NA325019000 | 35 | Cover - no logo | Ask for a price |
|
NA227059000 | 36 | Fixed handle | Ask for a price |
|
NA219003000 | 37 | M5 form a steel washer | Ask for a price |
|
NA236042000 | 38 | 10.0m x 18awg x 3 core cable (csa plug) | Ask for a price |
|
NA403039000 | 41 | Bucket handle | Ask for a price |
|
NA219105000 | 42 | No8 X 5/8 INCH LONG POZI PAN PLASTITE SCREW | Ask for a price |
|
NA206493000 | 43 | Wet dry connector | Ask for a price |
|
NA208026000 | 44 | Bucket handle spacer | Ask for a price |
|
NA219282000 | 45 | M5 x 16mm long pozi pan countersunk screw | Ask for a price |
|
NA206026000 | 46 | Polyprop ball | Ask for a price |
|
NA225087000 | 47 | Float cage support | Ask for a price |
|
NA225086000 | 48 | Float cage | Ask for a price |
|
NA225083000 | 49 | Float assembly gasket | Ask for a price |
|
NA220235000 | 50 | Float grommet | Ask for a price |
|
NA207011000 | 51 | Float cage gasket | Ask for a price |
|
NA207055000 | 52 | Gauze filter | Ask for a price |
|
NA227065000 | 53 | Fluid container assembly | Ask for a price |
|
NA303018000 | 54 | Braided solution tube & filter assembly ct machines | Ask for a price |
|
NA209400000 | 56 | Single filter grid | Ask for a price |
|
NA227640000 | 57 | 2 shot wheel assembly | Ask for a price |
|
NA227638000 | 58 | Black plain trim | Ask for a price |
|
NA227687000 | 58 | Red plain trim | Ask for a price |
|
NA227688000 | 58 | Blue plain trim | Ask for a price |
|
NA227689000 | 58 | Green plain trim | Ask for a price |
|
NA227690000 | 58 | Yellow plain trim | Ask for a price |
|
NA227396000 | 59 | Red threaded neck | Ask for a price |
|
NA227397000 | 59 | Blue threaded neck | Ask for a price |
|
NA227398000 | 59 | Green threaded neck | Ask for a price |
|
NA227399000 | 59 | Yellow threaded neck | Ask for a price |
|
NA227395000 | 59 | Black threaded neck | Ask for a price |
|
NA227346000 | 59 | Grey threaded neck | Ask for a price |
|
NA325439000 | 60 | Top motor housing (grey numatic logo) | Ask for a price |
|
NA325440000 | 60 | Top motor housing (white george logo) | Ask for a price |
|
NA325422000 | 61 | Bottom motor housing & wire clip assembly | Ask for a price |
|
NA325426000 | 61 | Blue container ct machines | Ask for a price |
|
NA325427000 | 61 | Green container ct machines | Ask for a price |
|
NA325428000 | 61 | Yellow container ct machines | Ask for a price |
|
NA325429000 | 61 | Grey container ct machines | Ask for a price |
|
NA325430000 | 61 | White container ct machines | Ask for a price |
|
NA325431000 | 61 | Red container + face gve machines | Ask for a price |
|
NA325417000 | 61 | Blue container + face gve machines | Ask for a price |
|
NA325432000 | 61 | Green container + face gve machines | Ask for a price |
|
NA325433000 | 61 | Yellow container + face gve machines | Ask for a price |
|
NA325434000 | 61 | Grey container + face gve machines | Ask for a price |
|
NA325435000 | 61 | White container + face gve machines | Ask for a price |
|
|
NA325422000 | 62 | Bottom motor housing & wire clip assembly | Ask for a price |
|
NA270167000 | 63 | Quick release mounting bracket | Ask for a price |
|
NA219327000 | 64 | 80mm long spring | Ask for a price |
|
|
NA218005000 | 65 | Nvm2b/2 individual disposable trapit bag (manufacturing) not shown | Ask for a price |
