Spare Parts for:

Nacecare

AVB9X Carpet Extractor with Brush 9 Gal

#NA802519300

The AVB9X carpet extractor includes a squeegee and rotating brush for deep carpet cleaning. This professional carpet washer includes two detachable 9-gallon tanks.

Ask for a price

Parts Schema

Upper Panel Serial Numbers 0001 and higher

SKU#	Label on drawing	Description	Ask for a price
NA151773000	1	Charis upper panel	Ask for a price
NA151906000	2	Charis uppor panel label	Ask for a price
NA152200000	3	3 position switch	Ask for a price
NA015217000	4	Switch	Ask for a price
NA015217000	5	Switch	Ask for a price
NA152940000	6	Rubber protection	Ask for a price
NA152908000	7	Thermal protection – 0,8a (220-240v)	Ask for a price
NA152930000		Thermal protection – 1,5a (100-120v)	Ask for a price
NA151280000	8	Gasket for upper panel	Ask for a price
NA015536000	9	Screw	Ask for a price
NA156175100	10	3 position special valve	Ask for a price
NA156260000	11	Elbow	Ask for a price
NA156860000	12	Extension	Ask for a price
NA157030000	13	Automatic coupling f-att.m. r1 8 1/8	Ask for a price
NA157581000	14	Cap a7 m. 1/8"	Ask for a price
NA156830000	15	Coupling fm 1/8-1/8 a5/z	Ask for a price
NA154925100	17	Side cover for charis handle	Ask for a price
NA154925200	18	Upper cover for charis handle	Ask for a price
NA151906110	19	Label for upper cover charis-one	Ask for a price
NA015536000	20	Screw	Ask for a price
NA154925300	21	Handle cylindric support	Ask for a price
NA155995000	22	Special screw diam.12	Ask for a price
NA155007000	23	Knob	Ask for a price
NA155171000	24	WASHER 5x15x1,5 UNI 6593 INOX	Ask for a price
NA155700000	25	SCREW TC+ 5x16 Zn	Ask for a price
NA154922100	26	Brush adjestment lever	Ask for a price
NA154922200	27	Brush lever cover	Ask for a price
NA154710400	28	Spring	Ask for a price
NA155083200	29	Spring support	Ask for a price
NA155746000	32	SCREW TC BRUGOLA 6x60 INOX	Ask for a price
NA155781200	33	Seeger d.12	Ask for a price
NA155201000	34	WASHER 12x24x1	Ask for a price
NA154750100	35	Pawl body	Ask for a price
NA154750500	36	Pawl sphere	Ask for a price
NA154750400	37	Pawl spring	Ask for a price
NA154750200	38	Pawls cap	Ask for a price
NA154750300	39	Pawl nut	Ask for a price
NA155972000	40	WASHER STK 17x24x0,5 PS DIN 988	Ask for a price
NA155672000	41	SCREW TE 8x50 UNI 5739 Zn	Ask for a price
NA1558206I0	42	SCREW 6x8 UNI 5739 INOX	Ask for a price
NA154925400	43	Plate	Ask for a price
NA015536000	44	Screw	Ask for a price
NA152160000	45	CABLE 3x1.5x15m WITH EURO PLUG	Ask for a price
NA152150000	45	Cable 3 x 14 awg x 15m	Ask for a price
NA152380000	46	Cable lock	Ask for a price
NA155350400	47	SCREW TC+ 3x16 Zn	Ask for a price
NA152361000	48	Fairlead	Ask for a price
NA152851000	49	Insulating plate	Ask for a price
NA155350400	50	SCREW TC+ 3x16 Zn	Ask for a price
NA158132000	51	Varistor for pump	Ask for a price
NA155012200	52	Complete wire for brush adjustment	Ask for a price
NA155012300	53	Complete wire for pump	Ask for a price
NA155470000	54	SCREW TC+ 4x8 DIN 7985	Ask for a price
NA151382000	55	Micro-switch support	Ask for a price
NA152770000	56	Micro-switch	Ask for a price
NA154700C00	57	Complete Pawl	Ask for a price
NA155010000	58	Conic pin	Ask for a price
NA155011000	59	Wire lock	Ask for a price
NA155730400	60	STOP DOWEL 4x4	Ask for a price
NA155012100	61	Complete wire for click	Ask for a price
NA152793500	62	External rectifier for shurflo pump	Ask for a price
NA155210000	63	Locking washer diam.12mm	Ask for a price
NA155510000	64	SCREW TC+ 4x16 INOX	Ask for a price
NA152950000	69	Fairlead with nut	Ask for a price
NA1558206I0	70	SCREW 6x8 UNI 5739 INOX	Ask for a price
NA156831000	71	Coupling fm a5z 1/4-1/8 cilindr	Ask for a price
NA1573501C0	72	Hose mm1/4 l240	Ask for a price
NA157621400	73	Coupling ff a3 1/4	Ask for a price
NA15687T000	74	Female quick disconnect coupling	Ask for a price
